Semi CNC Hydraulic Press Brake
Accuracy of CNC. Affordability of NC. Innovation by Monotech
Product Overview
At Monotech Engineers Pvt Ltd, we’ve bridged the gap between conventional and CNC technology with our revolutionary Semi CNC Hydraulic Press Brake. Unlike standard models, our proprietary design delivers true independent control of Y1 and Y2 hydraulic cylinders — electrically, without any mechanical restriction. This groundbreaking system, developed entirely in-house, provides CNC-level precision and extended machine life at 60–70% less cost than a full CNC press brake.
Applications of Semi CNC Hydraulic Press Brake
Our CNC Press Brakes are widely used across multiple industries for precision sheet metal bending.
Automobile
Used for manufacturing car body panels, frames, doors, and structural components.
Appliance Industry
Used in making refrigerators, ovens, washing machines, and home appliance panels.
Construction Industry
Used for roofing sheets, structural frames, and building components.
Electronics
Used for electrical panels, enclosures, and precision metal parts.
Aerospace
Used for aircraft panels, wing parts, and precision engineered components.
Operational Benefits
SASH PUNCH
GOOSENECK PUNCH
KNIFE PUNCH
4 V DIE
SPRING HEMMING DIE & PUNCH
RAIL TYPE 2 V DIE
Product Range
| Model No | Bending Force | Bending Length | Capacity | Clearpass | Ram Stroke | Open Height | Depth Throat | Speed mm/Sec | Fast Clamp | Motor H.P. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Approach | Pressing | Return | ||||||||||
| MT-PBF-316 | 30 TON | 1600 | 1600 x 2 | 1250 | 125 | 300 | 200 | 100 | 6 | 65 | 8 | 3 |
| MT-PBF-625 | 60 TON | 2500 | 2500 x 2 | 2000 | 150 | 340 | 200 | 100 | 6 | 80 | 12 | 5 |
| MT-PBF-632 | 60 TON | 3200 | 3200 x 2.5 | 2700 | 150 | 340 | 200 | 100 | 6 | 80 | 16 | 5 |
| MT-PBF-825 | 80 TON | 2500 | 2500 x 2 | 2000 | 150 | 340 | 250 | 100 | 6 | 80 | 12 | 7.5 |
| MT-PBF-832 | 80 TON | 3200 | 3200 x 2.5 | 2700 | 150 | 340 | 250 | 100 | 6 | 80 | 16 | 7.5 |
| MT-PBF-1025 | 100 TON | 2500 | 2500 x 3 | 2000 | 150 | 370 | 250 | 100 | 7 | 80 | 12 | 10 |
| MT-PBF-1032 | 100 TON | 3200 | 3200 x 4 | 2700 | 150 | 370 | 250 | 100 | 7 | 80 | 16 | 10 |
| MT-PBF-1040 | 100 TON | 4000 | 4000 x 5 | 3200 | 150 | 370 | 250 | 100 | 7 | 80 | 20 | 10 |
| MT-PBF-1232 | 120 TON | 3200 | 3200 x 4 | 2700 | 150 | 370 | 300 | 100 | 6 | 80 | 16 | 10 |
| MT-PBF-1240 | 120 TON | 4000 | 4000 x 5 | 3200 | 150 | 370 | 300 | 100 | 6 | 80 | 20 | 10 |
| MT-PBF-1520 | 150 TON | 2000 | 2000 x 4 | 2000 | 200 | 430 | 300 | 100 | 6 | 80 | 8 | 10 |
| MT-PBF-1625 | 160 TON | 2500 | 2500 x 8 | 2000 | 200 | 430 | 300 | 100 | 6 | 80 | 12 | 15 |
| MT-PBF-1632 | 160 TON | 3200 | 3200 x 6 | 2700 | 200 | 430 | 300 | 100 | 6 | 80 | 16 | 15 |
| MT-PBF-1640 | 160 TON | 4000 | 4000 x 5 | 3200 | 200 | 430 | 300 | 100 | 6 | 80 | 20 | 15 |
| MT-PBF-2032 | 200 TON | 3200 | 3200 x 8 | 2700 | 200 | 430 | 350 | 100 | 6 | 80 | 16 | 20 |
* Capacities rated for MS. (LTS 45g/mm²) Bending capacities stated are only representative and non dinding. Allow extra capacity nditions. Right to change specification, features without entice reserved. Compliance with safety requirements as per local regulations is responsibility of the user
Design & Construction
- ✔Bending Capacity: 63 to 600 Ton (customized)
- ✔Bending Length: 1600 mm to 6200 mm (as per requirement)
- ✔Axis Configuration: Y1, Y2, X, + V (3+1 Axis) with optional X1, X2, R1, R2, Z1, Z2 etc
- ✔Crowning System: Motorized or CNC-controlled hydraulic crowning
- ✔CNC Controller: CYBELEC CYBTOUCH 8 PS (Upgradable to CYBTOUCH 12 PS / VISI Touch / Delem / ESA)
- ✔Structure: Rigid mono-block welded frame with minimal deflection, FEA-analyzed and 3D-designed
- ✔Hydraulic Cylinders: Front-mounted cylinders for accurate, synchronized movement
What Makes Our Design Unique?
At Monotech Engineers, we engineer our CNC Press Brakes with a laser-sharp focus on accuracy, durability, and user convenience. Our design stands apart from others due to:
- ✔FEA-Analyzed Mono-Block Frame: Minimizes deflection during heavy bending operations, ensuring dimensional accuracy and long service life.
- ✔Motorized/CNC Hydraulic Crowning System: Delivers uniform angle precision across the entire bending length.
- ✔Forged & Honed Hydraulic Cylinders: Precision-machined with imported seals for jerk-free ram movement and consistent performance.
- ✔Imported HAWE Hydraulics (Germany): High-frequency response valves for real-time accuracy and energy-efficient flow control.
- ✔Backgauge on Linear Motion Guides: Allows micrometric adjustment, precision alignment, and resistance to crash.
- ✔Tooling Compatibility: ESegment-wise punch and die sets designed to match European standards with quick-release clamping for fast tool changes.
- ✔Flexible Automation Options: From basic 3+1 Axis to 6+1 Axis configurations with expandable controller upgrades.
Hydraulic Cylinders With Imported Seals
Forged & Honed Cylinder, machined on high accuracy VMC Machines & having a round joint with the ram to absorb sudden jerks.
Monotech press brakes are designed to increase your productivity and decrease your per unit cost. Design innovations based on our years of experience have resulted in faster speeds on the approach, bending, return and back gauge. Monotech Press Brake features a rigid mono-block frame for minimum deflection under load. Synchronized dual cylinders and Hawe Germany valves assure smooth, stable ram motion for high-quality, precision bends.
Strong Back Gauge System
Precise Reliable Strong
- ✔Fast And High Accuracy
- ✔Safe Movement
- ✔Adjustment Availability At Every Point
- ✔Resistance To Crash
- ✔Maintenance Free
Key Features & Accessories
Performance-Driven Design
Fast & Accurate Bending
High-speed movement with pre-set approach, bending, and return speeds
Forged Cylinders & HAWE Hydraulics
Ensures smooth ram motion and reliable operation
Chrome-Plated 42CrMo Tooling
Includes gooseneck, knife, sash, rail type 2V, and spring hemming dies
Laser & Mechanical Safety Systems
Prevent accidents and enhance operator confidence
Adjustable Front Sheet Supports & Foot Switches
Improve ergonomics and ease of use
Want to Know More?
Download our brochure or request more information to learn how Monotech can help you achieve your manufacturing goals.
The MONOTECH Advantage
Monotech Engineers operates with a modern, well-equipped manufacturing facility designed for precision engineering and heavy fabrication. Our infrastructure supports high-capacity production, ensuring seamless handling of raw materials, machining, assembly, and quality inspection — all under one roof. This enables faster turnaround, consistent quality, and reliable delivery timelines.
With over three decades of industry experience, Monotech Engineers has built a strong reputation in sheet metal machinery and industrial solutions. Our deep engineering expertise allows us to understand complex customer requirements and deliver machines that perform with precision, durability, and efficiency in demanding environments.
Our machines are widely used across diverse industries including automotive, fabrication, construction, and heavy engineering. From precision CNC machines to robust forming solutions, Monotech products are trusted for their performance, accuracy, and long operational life.
We believe in building long-term partnerships, not just delivering machines. Our growing base of satisfied clients reflects our commitment to quality, service, and continuous support. From installation to after-sales service, we ensure our customers operate with confidence and reliability.
Build Quality & Benefits
Heavy-Duty Frame Structure
Our CNC Press Brake Machines are built with a high-strength, welded steel frame designed to withstand continuous heavy-duty operations. The frame undergoes stress-relieving treatment to eliminate internal stresses, ensuring long-term structural stability, accuracy, and durability. Precision machining guarantees perfect alignment of all critical components, delivering consistent bending performance over years of operation.
Precision Bending System
The core of the CNC Press Brake lies in its advanced bending mechanism. Equipped with high-precision hydraulic cylinders and synchronized control, the machine ensures uniform force distribution across the entire bending length. This results in highly accurate bends, reduced material wastage, and repeatable performance even for complex profiles.
CNC Control & Automation
Our machines are integrated with advanced CNC controllers that allow multi-axis control and programmable bending sequences. Operators can easily input parameters such as angle, depth, and material type, enabling automated and highly precise operations. This reduces manual intervention, minimizes errors, and significantly increases productivity.
Back Gauge System
The CNC-controlled back gauge system ensures precise positioning of the workpiece for every bend. With high-speed servo motors and linear guides, it delivers accurate and repeatable positioning, even for intricate bending operations. This enhances efficiency and ensures consistency in batch production.
CNC Control & Automation
Our machines are integrated with advanced CNC controllers that allow multi-axis control and programmable bending sequences. Operators can easily input parameters such as angle, depth, and material type, enabling automated and highly precise operations. This reduces manual intervention, minimizes errors, and significantly increases productivity.
Back Gauge System
The CNC-controlled back gauge system ensures precise positioning of the workpiece for every bend. With high-speed servo motors and linear guides, it delivers accurate and repeatable positioning, even for intricate bending operations. This enhances efficiency and ensures consistency in batch production.
Hydraulic System Efficiency
The machine is equipped with a high-performance hydraulic system designed for energy efficiency and smooth operation. Advanced proportional valves ensure precise control of pressure and speed, while optimized hydraulic circuits reduce energy consumption without compromising performance. This results in lower operational costs and enhanced machine life.
Tooling & Flexibility
Our CNC Press Brake Machines support a wide range of punches and dies, allowing flexibility for various bending applications. Quick tool change systems enable faster setup times, making the machine suitable for both mass production and customized jobs.
Safety & Reliability
Safety is integrated at every level with features like light curtains, emergency stops, and overload protection systems. These ensure operator safety while maintaining uninterrupted production. The machine is designed to deliver reliable performance even in demanding industrial environments.
